Chevy Small Block - Long Water Pump Mid-Mount Ultra Alternator Only Serpentine System

The Chevy Small Block Mid-Mount Ultra Alternator-Only Serpentine System provides a compact, high-clearance serpentine drive solution for Chevy Small Block engines using a 7" standard-rotation long water pump. Its unique 9 o’clock mid-mount alternator position solves common fitment issues in tight engine bays, while the CNC-machined 6061-T6 billet aluminum construction ensures exceptional strength and precise alignment. Designed for classic mid- and full-size Chevy applications, this system delivers clean routing, reliable belt control, and a durable upgrade for efficient Chevy Small Block serpentine performance.

Application:

• Chevy small block
• 7" standard rotation long water pump

Product Notes:

• If using Billet Power-Steering Pump with driver-side A/C kits, may require modification to A/C bracket.
• Will not fit pre-1982 Corvettes without cross-member modification.
• Requires passenger-side hole for mounting.

 Kit Includes:

• Mid-mount alternator bracket for GM 10SI alternator
• Alternator pulley with fan and nose cover
• Water pump pulley for Chevy small block long water pump
• Crank pulley
• Mounting hardware

A/C kits include:

• Driver side bracket for Sanden 505 or 508 A/C compressor
• Billet aluminum cover for A/C compressor

Kits with power steering include:

•  Power steering bracket for 1966-1974 Saginaw keyway, 1975-1978 Saginaw press fit, or 1978-1987 Saginaw metric press fit power steering pump
•  Power steering pulley
• Optional Power-Steering Nose Cover Available: 360

Instructions:

20124

20160

22020

22070
