Small Block Chevy Style Track Serpentine System - Black Onyx

The March Performance Street Rod Style Track System is engineered for builders who demand maximum clearance and reliability in tight engine bays. This compact serpentine drive mounts the alternator and A/C compressor high and close to the block, providing the critical forward clearance needed for pre-1940s street rod applications.

Each system is CNC-machined from 6061-T6 billet aluminum for strength, accuracy, and a perfect fit. A larger diameter crank pulley improves accessory function at idle, while the custom super-short water pump provides the greatest radiator clearance available.

Kits include all pulleys, brackets, hardware, and a belt tensioning tool for straightforward installation. Available with or without power steering options, including GM Type II or Saginaw canister-style pumps.

Application:

Chevy Small Block

Note: Chevelle, Monte Carlo, El Camino,1970 & Newer Camaro and S10 will require remote power steering kits.

Will not fit pre 1982 corvettes without cross member modification.

Kit includes:

• 140 amp GM CS130 alternator
• Alternator pulley with nose cover
• Alternator Fan
• Sanden 7176 a/c compressor
• Aluminum reverse rotation short water pump
• Hard-coated Water Pump Pulley
• Alternator and a/c bracket
• Crank pulley
• Spring loaded pulley belt tensioner
• All Mounting Hardware

Kits with power steering include:

• Aluminum GM type 2 power steering pump (remote reservoir required) OR
• Canister style Saginaw keyway power steering pump
• Power steering pulley
• Bracket with mounting hardware

Instructions:

21100, 21150, 21155
